Ames, Iowa House Price Predictions with Machine Learning

Posted on Sep 24, 2020

Link to Github

The skills the author demonstrated here can be learned through taking Data Science with Machine Learning bootcamp with NYC Data Science Academy.

Objective and Overview of Ames Housing Price Project

The objective of this third project was to build machine learning models to predict house prices as part of the Kaggle competition House Prices: Advanced Regression Techniques. In this competition, we used the Ames Housing dataset, which was compiled by Professor Dean De Cock of Truman State University, and which describes the sale of residential properties in Ames, Iowa during the period 2006 - 2010.

This dataset contains a total of 2919 observations split across 80 different explanatory variables (23 nominal, 23 ordinal, 14 discrete, and 20 continuous) that impact home values, captured in the SalePrice variable in this dataset. The data is split equally between a training dataset containing 1460 observations and a testing dataset containing 1459 observations. Here were the steps taken to create a highly accurate model:

  1. Data exploration
  2. Data cleaning
  3. Feature engineering
  4. Feature selection on level 0 models
  5. Hyper-parameter tuning on level 0 models
  6. Stacking the level 0 models into a level 1 model

Ames House Attributes vs Prices - Data Exploration

The first step in this analysis was checking for outliers in the dataset that could potentially skew our model predictions. Given that the GrLivArea variable, which captures above grade (ground) living area in square feet, exhibited a 0.71 positive correlation with SalePrice in the training dataset, I got a high degree of confidence that it would offer strong predictive power later on and would by extension provide a good screen for potential outliers. Plotting the SalePrice dependent variable vs GrLivArea in our training dataset revealed two seeming outliers exceeding 4,500 sqft in total area:

Ames, Iowa House Price Predictions with Machine Learning

Checking the distribution of the GrLivArea variable in the testing dataset confirmed these two outlier points could potentially end up skewing our predictions, as only one house in the testing dataset exceeds >4,500 sqft in total area. The two previously highlighted points in the training dataset were therefore removed.

Ames, Iowa House Price Predictions with Machine Learning

The same process was performed with LotFrontage. One outlier with >300ft LotFrontage was found in the training dataset and was subsequently removed as the testing dataset did not contain any observations with LotFrontage > 200ft:

Ames, Iowa House Price Predictions with Machine Learning

Ames Housing Prices - Data Cleaning

Careful reading of the supporting documentation on each variable informed the imputation process. Most of the imputation process dealt with variables having ‘NA’ values that corresponded to the absence of a feature. These ‘NA’ values were replaced by str(None) or 0 values depending on the type of the variable. For instance, the 80 ‘NA’ values in the qualitative feature BsmtFinType2 meant ‘No Basement’ and were therefore mapped to str(None).

In the case of numerical variables, imputation was performed using either the mean or the mode, whichever was most appropriate. For instance, the 486 missing values in the LotFrontage variable were imputed using a groupby + aggregate of mean LotFrontage values for each Neighborhood (no NA’s), as it was observed that LotFrontage values for each neighborhood were tightly distributed. On the other hand, the one missing value in the continuous variable GarageArea was imputed to zero as it was assumed that the absence of a value most likely entailed the absence of a garage. Some numerical variables, such as MoSold, were converted to string type in order for proper dummification to take place later on.

For categorical variables, values were imputed using the mode of that feature set. The one missing value in the Exterior1st variable, for example, was imputed with the mode VinylSd, which corresponded to a house with a Vynil siding exterior. Other categorical variables were dropped entirely from the dataset when one value dominated the distribution, such as RoofMatl, which was dropped as CompShg accounted for 98% of values.

Feature Engineering

For categorical variables with string values, these were converted to ordinal variables using dictionaries mapping the string values to integers. For instance, the KitchenQual variable with categories Excellent, Good, Typical, Fair, and Poor, was mapped to {'Po':1, 'Fa':2, 'TA':3, 'Gd':4, 'Ex':5} once its one missing value was imputed to the mode (Typical in this case). A total of fifteen variables were transformed using this methodology.

In addition, certain binary variables were created to capture the presence or absence of certain features. The Has2ndFloor binary variable, for instance, took on a value of 1 if 2ndFlrSF > 0, indicating that a house had a second floor. Likewise, the YearsSinceRemodel variable, capturing how many years it had been since the house was remodeled, was computed by taking the difference of YrSold and YearRemodAdd. Some of the other features that followed similar methodologies were:

  1. Remodeled – Binary variable that takes 1 if YearBuilt != YearRemodAdd
  2. RecentRemodel – Binary variable that takes 1 if YearRemodAdd = YrSold
  3. SqYearBuilt – Continuous variable constructed by exponentiating YearBuilt to the second power
  4. YearSoldYearBuilt – Binary variable that takes 1 if YearBuilt = YrSold
  5. Age – Continuous variable constructed by subtracting YrBuilt from YrSold
  6. CentralAir - Binary variable that takes 1 if CentralAir = ‘Y’
  7. Area1st2nd – Continuous variable constructed by summing 1stFlrSF and 2ndFlrSF
  8. HasFireplace - Binary variable that takes 1 if Fireplaces > 0
  9. HasShed – Binary variable that takes 1 if MiscFeature = Shed
  10. RR_Proximity – Binary variable that takes 1 if Condition1 = 'RRNn', 'RRAn', 'RRNe', 'RRAe'

Feature Selection on Level 0 models - Pt. 1

Given the large number of features in the dataset that could cause simple linear models to overfit, I decided to skip Linear Regression and to start directly with penalized linear models that would tend to overfit the data less. The five models I was therefore interested in testing were Ridge, Lasso, Random Forests Regressor, Gradient Boosting Regressor and XGBoost:


Table A. Different Machine Learning Trained on the Data
Model Category Type Python
Linear Models Ridge (scikit-learn) Ridge
  Lasso (scikit-learn) Lasso
Tree-based Models Gradient Boosting (scikit-learn) GradientBoostRegressor
  Random Forest (scikit-learn) RandomForestRegressor
  XGBoost XGBoost) XGBoostRegressor

Feature selection was approached two separate ways to test which worked best for different models, the first using correlation values and the second using Recursive Feature Elimination ("RFE"). The first approach was to select features based on the absolute value of their Pearson correlation coefficient with SalePrice and to fit each of the models on these different feature subsets.

In order to speed up this process and to standardize the way selections were made by correlation coefficient value, I wrote a Python script using object-oriented programming that selected these features based on different input correlation cutoff points. All models were tested using cross validation with 2 train folds and 1 test folds each containing 33.3% of the data. The preliminary results following this methodology for each of the models with no hyperparameter tuning can be seen below:


Table B. Feature Selections and CV RMSE & Kaggle Scores using Pearson Correlation Values
Model Variables Used CV Neg RMSE Kaggle Score
Ridge  99 -766k 0.1458
Lasso  98 -780k 0.1403
Gradient Boosting All variables -548k 0.1367
Random Forest All variables -714k 0.1395
XGBoost 151 -687k 0.1388

Feature Selection on Level 0 models - Pt. 2

The second approach was to use Recursive Feature Elimination to select variables by recursively considering smaller and smaller sets of features. RFE works by repeatedly building models and selecting the best or worst performing feature at any given point, setting this feature aside and repeating the process with the rest of the features. RFE computes which features should be selected-out at every stage by looking at the feature’s weight coefficients for linear models and feature importances for tree-based algorithms.

Once these features selected-out, RFEcv calculates the new root mean squared error score on the validation data, and the subset of features left at the step that gives the highest score on the validation data is considered to be "the best n_features" subset. Scikit-learn’s RFEcv library was used to implement this recursive feature selection. The following graph shows trends in RMSE vs number of features for each of our models:


Table C. Feature Selections and CV RMSE & Kaggle Scores using RFE
Model Variables Used CV Neg RMSE Kaggle Score
Ridge  211 -697k 0.1385
Lasso 222 -723k 0.1394
Gradient Boosting 210 -571k 0.1320
Gradom Forest 32 0874k 0.1464
XGBoost 46 -519k 0.1333


As can be seen by comparing the two tables, all models except for Random Forests saw cross-validated RMSE score improvements using the RFE-selected feature subsets. The RFE-selected feature subsets were therefore used for these models while the Random Forests model was trained using all variables going forward.

The feature importance rankings of the RFE-selected feature subsets provided some interesting preliminary insights, such as that the overall material and finish of the house was a strong predictor of SalePrice in our XGBoost model:

Hyper-parameter Tuning

Once the data processed and the features selected, the next step in the process was finding the best hyperparameters for each of our models to ensure high model accuracy. Hyper-parameter tuning is important to make sure that models are not either overfitting or underfitting and to control for the bias-variance tradeoff.

Hyperparameters such as n_estimators or learning_rate for tree-based models can also significantly impact model run time and can in certain cases make the added computational expense not worth the added accuracy benefit they yield. The GridSearchCV package in Python sklearn was used to complete an exhaustive search of the available hyperparameters and yielded higher accuracy scores for each of our models after tuning took place. The different model predictions and how they compared to the true SalePrice values represented by the straight line can be seen below:

Stacking the Models

The last step in the process was stacking the models. Model stacking is a method that uses the predictions of different Level 0 models to train a Level 1 meta-model that predicts the same y variable and can oftentimes produce an even more accurate prediction of the target variable. In this way, the Level 1 model can weigh the predictive strengths and weaknesses of the different models and capture different kinds of relationships in the data that an individual model may miss.

The tradeoffs for this potentially higher accuracy are higher computational expense as well as lower interpretability, as individual features can no longer be examined separately to better understand what each contributes to the model. This tradeoff of lower interpretability is addressed in the conclusion. For the purposes of this project, a Level 1 model was trained on top of our Ridge, Lasso, RandomForests, XGBoost, and Gradient Boosting Models and as expected outperformed all individual model components, yielding a final Kaggle score of 0.13072.

Conclusion About Ames Housing Prices

Given our stacked Level 1 model trains on the predictions of the Level 0 models, I wanted to take a step back to analyze the feature importances in our Level 0 models. The following are some of the insights gleaned from the outputted feature importances of each model as well as some recommendations for residential real estate buyers and sellers:

XGBoost: Qualitative variables such as OverallQual and ExterQual are most important

  • Sellers: Consider investing more into quality of the external finish of a house to fetch higher prices
  • Buyers: Consider buying houses with no/low-quality basements and excavating/enlarging/improving these yourself if cheaper in the aggregate


Random Forests: OverallQual, TotalArea, Area1stArea2nd, LotFrontage are most important

  • Sellers: Consider improving fireplace quality to fetch higher prices
  • Buyers: Consider buying houses with no garage and building one yourself if cheaper in the aggregate


Gradient Boosting Regressor: OverallQual, LotArea, BsmtQual & YearBuilt are most important

  • Sellers: Consider investing in Central Air conditioning to fetch higher prices
  • Buyers: Consider buying older houses and remodeling these yourself


Linear Models: LotArea, Neighborhood variables are most important

  • Sellers: Consider building an open porch to increase house value
  • Buyers: Consider building an open porch yourself to save money if cheaper in the aggregate


Thanks for reading!
